Place of Origin:
Shenzhen, China
Brand Name:
Polcd
Certification:
RoHS, ISO9001
Model Number:
P028B126P-IPSV2
Contact Us
Video
Parameter:
| Model | P028B126P-IPSV2 |
| Screen Size | 2.8 inch |
| Number of Pixel | 240RGB(H)x320(V) |
| Display area | 43.2(H)x57.6(V)mm |
| Pixel pitch | 0.18(H)x0.18(V)mm |
| Pins | 24 pins |
| Outline Dimension | 50.00x69.20x2.30mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally Black |
| Viewing Direction(eye) | ALL |
| Display Color | 262K |
| Luminance(cd/m2) | 900 nit |
| Contrast Ratio | 1200:1 |
| Interface | MCU 8bit |
| Back-light | LED Side-light type |
| Drive IC | ST7789P3-G6 |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
