Place of Origin:
Shenzhen, China
Brand Name:
Polcd
Certification:
RoHS, ISO9001
Model Number:
P043B030-V2
Contact Us
Video
Parameter:
| Model | P043B030-V2 |
| Screen Size | 4.3 inch |
| Number of Pixel | 480RGB(H)x800(V) |
| Display area | 56.16(H)x93.55(V)mm |
| Pixel pitch | 0.039(H)x0.117(V)mm |
| Pins | 45 pins |
| Outline Dimension | 60.00x104.25x2.6mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally Black |
| Viewing Direction(eye) | ALL |
| Display Color | 262K |
| Luminance(cd/m2) | 400 nit |
| Contrast Ratio | 1500:1 |
| Interface | RGB 18bit |
| Back-light | LED Side-light type |
| Drive IC | ST7701S |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
