Place of Origin:
Shenzhen, China
Brand Name:
Polcd
Certification:
RoHS, ISO9001
Model Number:
P035C013-V6-CTP-911
Contact Us
Video
Parameter:
| Model | P035C013-V6-CTP-911 |
| Screen Size | 3.5 inch |
| Number of Pixel | 320RGB(H)x480(V) |
| Display area | 48.96(H)x73.44(V)mm |
| Pixel pitch | 0.153(H)x0.153(V)mm |
| Pins | 40 pins |
| Outline Dimension | 54.48x84.71x3.40mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally white |
| Viewing Direction(eye) | 12 0’CLOCK |
| Gray inversion direction | -- |
| Display Color | 262K |
| Luminance(cd/m2) | 300 nit |
| Contrast Ratio | 500:1 |
| Surface treatment | -- |
| Interface | MCU 8/16bit SPI 3/4 wire |
| Back-light | LED Side-light type |
| Drive IC | ILI9488 |
| CTP IC | GT911 |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
