Place of Origin:
Shenzhen, China
Brand Name:
Polcd
Certification:
RoHS, ISO9001
Model Number:
P154H008-40
Contact Us
Video
Parameter:
| Model | P154H008-40 |
| Screen Size | 1.54 inch |
| Number of Pixel | 240RGB(H)x240(V) |
| Display area | 27.72(H)x27.72(V)mm |
| Pixel pitch | 0.1155(H)x0.1155(V)mm |
| Pin | 40 pin |
| Outline Dimension | 31.52x33.72x2mm |
| Pixel arrangement | RGB Vertical Stripe |
| Display mode | Normally Black |
| Viewing Direction(eye) | ALL |
| Display Color | 262K |
| Luminance(cd/m2) | 350 nit |
| Contrast Ratio | 1200:1 |
| Interface | RGB666 |
| Back-light | LED Side-light type |
| Drive IC | ST7789T3 |
| Operation Temperature | -20~70℃ |
| Storage Temperature | -30~80℃ |
